ServiceStrong technical force, complete experimental conditions, advanced research and development equipment, and rich production experience
-
AboutThe Institute is engaged in the research and development of new technologies, new processes, new products and new equipment of composite materials, focusing on the manufacture of intelligent equipment of composite materials, and providing high-efficiency and low-cost overall solutions for composite material manufacturers.
-
NewsQinyang Composite Materials Research Institute welcomes industry colleagues to visit and guide. We are willing to work hand in hand with colleagues in the industry to seek common plans for the development of the composite industry and create a bright future for the development of the composite industry.
Technical Support
R & D of complete sets of production equipment
Optimization of Bamboo Reinforced Composite Pipeline Technology and Equipment
Process Equipment Optimization of Continuous Extrusion Sand Inclusion Pipeline
A variety of hollow wall structure tube process equipment
Optimization of grid automatic cloth yarn machine
Grating continuous production line
Fabrication of Knitting Felt from Fiber Scraps
Thermoplastic composite pipe online winding equipment
Optimization of intelligent production equipment for composite utility poles
PVC/FRP Composite Pipe Continuous Production Line
Continuous production process equipment without steel strip
R & D of supporting production equipment
High precision micro glue pump
High Viscosity Resin Pump
Manganese steel strip welding machine
Chain type pipeline tractor
Crawler type pipeline tractor
0 degree axial yarn cloth machine for pipe production
RGV intelligent navigation off-line transfer vehicle
Steel strip fast welding equipment
Closed glue spraying device
Variable diameter mold for continuous production of pipese
R & D of high-tech products
Bamboo strips for continuous winding
Fiberglass steel strips for continuous winding
FRP Pipe Sleeve Joint
Fiberglass Knitted Mat for Continuous Winding
Part of the project research achieved phased results
Adhere to the diversification of technical cooperation, actively carry out research cooperation and exchange of composite materials at home and abroad, and accelerate the improvement of R & D strength and the output and application of high-tech achievements.
01
No steel strip modeling technology: One of the biggest defects of the current continuous winding production equipment is that it is necessary to use closed-loop steel strips to establish a pipeline core mold. Due to the elastic effect of the steel strips, the curing of the resin is affected and the pipeline leakage is easily caused. There will be spiral ripples on the inner wall of the pipeline, which will affect the hydraulic properties of the pipeline. The steel strip is easy to deform or break and damage due to rigid fatigue during use, generally, the steel strip needs to be replaced every 1km or so of production. The process of replacing the steel strip is complicated, the technical requirements are high, the welding of the steel strip is difficult, the specialty is strong, and the use of the steel strip is labor-consuming and time-consuming. 65 manganese steel has about 8000 people per ton and 70 manganese steel has about 20000 yuan per ton, which increases the operating cost. In view of this defect, our newly developed continuous winding production equipment has realized the innovative change of core mold construction without steel strip, which can greatly reduce the cost of consumables, shorten the mold change time and improve production efficiency. The operation of non-steel belt entanglement equipment is more stable, the production efficiency and pipeline quality are further improved, and the cost of raw materials and equipment operation is further reduced, so it is more suitable for market demand and has stronger market competitiveness. At present, the continuous production equipment for small-diameter FRP pipes without steel belts has been mass-produced and applied in Changsha and other places on a large scale, which has been highly recognized by users. Continuous production equipment for large-diameter FRP pipes without steel belts and continuous production equipment for large-diameter FRP pipes without steel belts and hollow walls have been successfully developed and have applied for national patents.
02
A variety of wet extrusion sand technology. Through the high-strength extrusion of resin mortar, the resin content of sand-filled layer can be reduced from 15-18% of conventional bulk sand-filled layer to 7-8%, which greatly reduces the cost of raw materials. At the same time, the compactness of sand-filled layer is increased, the structural strength of the pipeline is improved, and the problem of small interlayer shear force of sand-filled pipeline by reciprocating winding cloth pocket method is effectively solved. This production process can replace the centrifugal casting production process and provide users with FRP pipes with better mechanical properties.
03
On-line winding fiber reinforced thermoplastic pipe forming technology has developed a new way for the innovation and upgrading of FRP pipe enterprises; lightweight high-strength hollow wall structure pipe forming technology and new grid wall structure pipe forming technology can produce FRP with lower cost and higher ring stiffness Pipes can also provide a variety of high-strength and lightweight solutions for glass steel pipes and tank products.
04
The continuous winding composite material pipeline equipment of our institute is continuously optimized and upgraded, and the innovative technology provides strong technical support for pipeline production enterprises. Newly developed and innovative technologies include: ① Continuous production without steel belt; ② Bamboo reinforced composite pipe; ③ Hollow wall structure pipe; ④ Thermoplastic composite pipe; ; ⑧ high-precision micro-glue pump; ⑨ 0-degree axial yarn; ⑩ airtight spray glue.
Research Institute is engaged in the research and development of new technologies, new processes, new products and new equipment of composite materials, focusing on the manufacture of intelligent equipment of composite materials, and providing high-efficiency and low-cost overall solutions for the "one-to-one" of composite material manufacturers
